Description
Product Parameters:
- Power Supply: 110V/220V AC 60Hz/50Hz
- Dimensions: L1600W650H1280mm
- Speed: 4000PCS/H
- Weight: 300kg
- Power: 250W
- Air Pressure: 4-6kg/cm²
Product Description:
- The machine is equipped with a Japanese Mitsubishi PLC control system, featuring a human-machine interface touchscreen. It is designed for ease of use, offering a simple operation process.
- Suitable for the forming of radial components such as LEDs, electrolytic capacitors, transistors, safety capacitors, metallized film capacitors, quartz crystals, and more.
- Forming shapes include 90-degree bends, inward bends, outward bends, front and rear bends, K-bending, and both long and short leads. Customization is available based on customer requirements.
- The automatic vibrating bowl feeder feeds components into the machine, which then completes the processes of clamping, lead straightening, polarity detection, orientation, secondary testing, waste ejection, lead cutting, and forming in one continuous cycle. Additional processes can be added based on special requirements.
- Features a modular die set, making mold changes quick and convenient. Each set of molds can be individually adjusted. The tooling is made of Japanese-imported steel for high durability.
- The elastic rack-style part holder ensures a secure grip without damaging the component. Similar-sized parts can be processed without the need to change the holder.
